DIN 267-26

Fasteners – Technical delivery conditions – Steel spring washers for bolt/nut assemblies

English 1987
0.000
DIN
Detailed Information

This standard applies to steel spring washers for use with bolt/nut assemblies and dealt with the following standards:
DIN 127 Spring lock washers with tang ends and square ends
DIN 128 Curved and wave spring lock washers
DIN 137 Curved and wave spring washers
DIN 6796 Conical spring washers for bolt/nut assemblies
DIN 6904 Spring washers for screw assemblies
DIN 6905 Spring lock washers for screw assemblies
DIN 6908 Conical spring washers for screw assemblies
DIN 6913 Spring lock washers with safety ring
DIN 7980 Spring lock washers for cheese head bolts
It is recommended that this standard also be applied for steel spring washers for bolt/nut assemblies which have not been standardized.
Spring washers made from materials other than spring steel are not the subject of this standard.

Download File
(Log in to download spec.)
